InteliSys NT BaseBox GeCon
InteliSys NT BaseBox GeCon
Comprehensive paralleling gen-set controller
Parallel operation up to 32 gen-sets
High level control for complex systems
CHP and gas engine controller
Key features
- Load sharing and VAr sharing via CAN
- Virtual shared inputs and outputs via CAN
- Support of wide range of applications
- Single or multiple gen-sets in parallel to mains operation with automatic back up function,
- multiple island operation
- Advanced power management function
- Customizable load control in parallel to mains
- Wide range of ECU support
- Extended communication capabilities
- Built-in web server
- Full Modbus slave support
- GPS and AirGate support and more
- Highly configurable
- Timers,Extended internal PLC , Force values and more Compatible with ComAp's InteliVision displays
- Active e-mail messaging and SMS
- Extensive built-in protection functions
- Standard protections
- User configurable protection
- Extendable with ComAp's extension modules
- True RMS (TRMS) is used with Voltage, Current and Power measurement
| Technical Data | |
| Power Supply Range | 8 – 36 VDC |
| Operating temperature | -40°C to 70°C |
| Number of binary inputs | 16 non-isolated |
| Number of binary outputs | 16 non-isolated |
| Number of analog inputs | 4 non-isolated |
| Magnetic pick-up Voltage input range |
2 Vpk-pk to 50 Veff |
| Current Measurement Inputs | 3 ph-n Gen voltage 3 ph-n Mains/Bus voltage |
| Voltage Measurement Inputs | 3 ph Gen current 1 ph Mains current galvanically isolated |
| Voltage regulator output Type | 5 V TTL PWM / ± 10 VDC with IG-AVRi interface |
| Speed governor Voltage output | ± 10 VDC / max.15 mA |
