InteliLite NT MRS 3 Gen-Set Controller


InteliLite NT MRS 3 Gen-Set Controller


InteliLite NT MRS 3 Manual Remote Start (MRS) Gen-set Controller

Model No/Model code : IL-NT MRS 3
Compact gen-set controller for single operating genset
Manual and remote start (MRS) applications
Easy to setup
Wide gen-set monitoring and protection
Running hours event and performance log
Multiple languages (user changeable) in controller, even more in installation suite
Plug-in extension modules capability
Automatic SMS on alarm or event & gen-set control over SMS*
Automatic GCB control
D+ preexcitation terminal
True RMS measurement
3 phase power measurement
3 configurable analog inputs
4 binary inputs
4 binary outputs

* Plug-in module required

Inputs/Outputs overview
Model: IL-NT MRS 3
BIN: 4+8*
BOUT: 4+8*
AI: 3
AOUT: 8*
COM1: Y*
COM2:Y*
CAN: N
RPM: N
Gen.Voltage: Y
Mains Voltage: N
Gen.Current:  Y


Note:
* With optional plug-in module
Y -Available
N -Not available

InteliLite NT MRS 3 Controller/Function

Voltage supply 8-36V DC
Operating temperature IL-NT -20 to 70°C
Operating temperature IL-NT LT# -40 to 70°C
Nominal frequency 50-60 Hz
Nominal input current (from CT) 5 A
Number of Binary inputs 4
Number of Binary outputs 4
Not electrically separated
Number of inputs
3
Galvanically separated
Maximal CAN bus length
200m
Dimensions 180x120x55mm
Weight 450g

» InteliLite IL-MRS3 Manual Guide
  • InteliLite NT MRS 3 Gen-Set Controller
    Art. nr.
    GSC22
    InteliLite NT MRS 3 Gen-Set Controller
